The LM551B is designed to produce a high-quality cut for any golf course around the world. Equipped with  22″ & 26″ units along with optional accessories, Baroness’ new midweight 5-unit fairway mower allows you to create the best configuration to meet your turf conditions. The forward and backward slide function of the rear cutting units increase contour following whilst minimizing uncut turf. The LM551B’s mower units has an industry leading range of motion combined with the unique tension support and down pressure features, allows the machine to consistently and accurately follow the most severe undulating surfaces. Equipped with Kubota V1505-CR-TE5 engine for solid reliability.







Key Features

Cross circuit

Cross circuit

The cross circuit system works by connecting the hydraulic flow from either front wheel to the opposite rear wheel in a cross, as its name implies. The cross circuit drive system combines the turning abilities of a parallel circuit with the climbing capabilities of a series circuit.
Optional Cutting Units

Optional Cutting Units

The LM551 has multiple options of cutting units 22" and 26" that can be fitted to better match the machine to your course. The LH52 unit, which  has a 127mm diameter reel, the LH62/66 & LS66 unit with a 163mm diameter reel. Each cutting unit has the option of 9 or 7 blade reels and can be fitted with a groomer, power brush, front & rear roller scraper and newly designed PE grass boxes. *Groomer and power brush can be fitted as a combination or individually on LH units only.
Outstanding Serviceability

Outstanding Serviceability

Superb access to make all servicing and adjustments very straightforward. Adjustment of the cutting cylinders and bedknives is assisted by the ability to turn off the reel motor drive, removing hydraulic circuit resistance, making turning the cutting cylinders a breeze.
The Heart of Baroness

The Heart of Baroness

At the heart of every Baroness reel mower is the cutting cylinder and bedknife. No-one takes more care than Baroness! Every cutting cylinder is individually balanced before being installed and our heat treatment process ensures that the cutting edges of both our cutting cylinders and bedknives stay sharp and true.
B-ACT

B-ACT

B-ACT - BARONESS aggression cutting technology. Most of the mowers and mower units produced by Baroness are eqiupped with B-ACT. B-ACT allows the end user to adjust the cutting aggression to better fit their individual course needs.
